Report der Symbolbibliothek
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Absperrarmatur |
|
|
|
|
|
|
Absperrarmatur m. Entleerung |
|
|
|
|
|
|
Absperrschieber |
|
|
|
|
|
|
Füllkombination |
|
|
|
|
VR(kalt) = 0,20 l/s pminFL(kalt) = 1500 hPa |
|
KFR-Ventil |
|
|
|
|
|
|
Kompensator |
|
|
|
|
|
|
Probenahmeventil |
|
|
|
|
|
|
Rohrtrenner |
|
|
|
|
|
|
Rohrunterbrecher |
|
|
|
|
|
|
Rückflussverhinderer |
|
|
|
|
|
|
Trinkwasser MAG |
|
|
|
|
|
|
UP-Absperrarmatur |
|
|
|
|
|
|
UP-Durchgangsventil |
|
|
|
|
|
|
Vollstromabsperrung AP |
|
|
|
|
|
|
Vollstromabsperrung UP |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Anfangs- bzw. Übergabepunkt |
|
|
|
|
|
|
Be- und Entlüfter |
|
|
|
|
VR(kalt) = 0,00 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,00 l/s pminFL(warm) = 1000 hPa |
|
Entleerung |
|
|
|
|
VR(kalt) = 0,00 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,00 l/s pminFL(warm) = 1000 hPa |
|
Geodätischer Nullpunkt (Trinkwasser) |
|
|
|
|
|
|
Hausanschlussgruppe |
|
|
|
|
|
|
Hausanschlusspunkt |
|
|
|
|
|
|
Layer Verbindung |
|
|
|
|
|
|
Sicherheitsventil |
|
|
|
|
|
|
Stopfen |
|
|
|
|
VR(kalt) = 0,00 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,00 l/s pminFL(warm) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Anschlussteil |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1250 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1250 hPa |
|
AquaClean 6000 Aufsatzgerät |
|
|
|
|
VR(kalt) = 0,16 l/s pminFL(kalt) = 1000 hPa |
|
AquaClean 8000 |
|
|
|
|
VR(kalt) = 0,04 l/s pminFL(kalt) = 1000 hPa |
|
Augendusche |
|
|
|
|
VR(kalt) = 0,00 l/s pminFL(kalt) = 1000 hPa |
|
Ausgussbecken PWC |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa |
|
Auslaufventil Gartenschlauch (kein Dauerverbr.) |
|
|
|
|
VR(kalt) = 0,42 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,42 l/s pminFL(warm) = 1000 hPa |
|
Auslaufventil mit Luftsprudler |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Auslaufventil ohne Luftsprudler |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 500 hPa VR(warm) = 0,30 l/s pminFL(warm) = 500 hPa |
|
FK 4 (Auslaufventil mit Rohrtrenner) |
|
|
|
|
VR(kalt) = 0,78 l/s pminFL(kalt) = 1900 hPa VR(warm) = 0,78 l/s pminFL(warm) = 1900 hPa |
|
Frosti Plus (kein Dauerverbr.) |
|
|
|
|
VR(kalt) = 0,67 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,67 l/s pminFL(warm) = 1000 hPa |
|
Getränkautomat |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa |
|
Kochendwassergerät |
|
|
|
|
VR(kalt) = 0,10 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,10 l/s pminFL(warm) = 1000 hPa |
|
Notdusche |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1500 hPa |
|
Sicherheitstrennstation FK 5 |
|
|
|
|
VR(kalt) = 0,83 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,83 l/s pminFL(warm) = 1000 hPa |
|
Spülmaschine PWC |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 500 hPa |
|
Stand WC AP-Druckspüler |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1200 hPa |
|
Stand WC AP-Hochspülkasten |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Stand WC AP-Spülkasten |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Urinal AP-Druckspüler |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa |
|
Urinal UP-Druckspüler |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa |
|
Urinal UP-Druckspüler m.Sensor |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa |
|
Verbraucher |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Wand WC AP-Spülkasten |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Wand WC UP-Druckspüler |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1200 hPa |
|
Wand WC UP-Spülkasten Bet. von oben |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Wand WC UP-Spülkasten Bet. von vorne |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Wand WC UP-Spülkasten Bet. von vorne, Geruchsabsaugung |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Wand WC UP-Spülkasten m. Stützklappgriffen |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Waschmaschine PWC |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 500 hPa |
|
Waschtisch PWC |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
AP-Badewanne |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
AP-Dusche |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
AP-Dusche m. Thermostat |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1200 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1200 hPa |
|
AP-Reihendusche |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Ausgussbecken PWH/PWC |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Bidet |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Duscharmatur |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Duscharmatur m. Thermostat |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1200 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1200 hPa |
|
Fußwaschbecken |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Reihenwaschanlage |
|
|
|
|
VR(kalt) = 0,05 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,05 l/s pminFL(warm) = 1000 hPa |
|
Schwenkarmatur PWH/PWC |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Spüle m. Einlocharmatur |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Spüle m. Einlocharmatur + Geschirrspüler |
|
|
|
|
VR(kalt) = 0,14 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,14 l/s pminFL(warm) = 1000 hPa |
|
Spüle m. Wandarmatur |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Spüle m. Wandarmatur + Geschirrspüler |
|
|
|
|
VR(kalt) = 0,14 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,14 l/s pminFL(warm) = 1000 hPa |
|
Spülmaschine PWC/PWH |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
TECEone Dusch WC UP |
|
|
|
|
VR(kalt) = 0,09 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,09 l/s pminFL(warm) = 1000 hPa |
|
UP-Badwanne |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
UP-Dusche |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
UP-Dusche m. Thermostat |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1200 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1200 hPa |
|
UP-Komfortdusche |
|
|
|
|
VR(kalt) = 0,20 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,20 l/s pminFL(warm) = 1000 hPa |
|
UP-Komfortdusche m. Thermostat |
|
|
|
|
VR(kalt) = 0,20 l/s pminFL(kalt) = 1200 hPa VR(warm) = 0,20 l/s pminFL(warm) = 1200 hPa |
|
UP-Komfortdusche m. Thermostat + Brause |
|
|
|
|
VR(kalt) = 0,25 l/s pminFL(kalt) = 1200 hPa VR(warm) = 0,25 l/s pminFL(warm) = 1200 hPa |
|
UP-Reihendusche |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Verbraucher PWH/PWC |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Wannenarmatur |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Waschmaschine PWC/PWH |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Waschtisch m. Einlocharmatur |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Waschtisch m.Wandarmatur |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Apparat allg. (mit rot. Teilen) |
|
|
|
|
|
|
Apparat allg. (ohne rot. Teile) |
|
|
|
|
|
|
Dosieranlage |
|
|
|
|
|
|
Enthärtungsanlage |
|
|
|
|
|
|
Filter |
|
|
|
|
|
|
Wasserzähler |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Armbadeplatz |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Dusche gefliest |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Gipsbeckenanlage |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Gipsbeckenanlage Wandarmatur |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Hubbadewanne |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Instrumentenspültisch |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Instrumentenspültisch Wandarmatur |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Medizinische Badewanne |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1000 hPa VR(warm) = 1,00 l/s pminFL(warm) = 1000 hPa |
|
Pflegearbeitsraumkombination (mit Waschmaschine) |
|
|
|
|
VR(kalt) = 1,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 1,15 l/s pminFL(warm) = 1000 hPa |
|
Pflegearbeitsraumkombination Wandarmatur (m. Waschmaschine) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1000 hPa |
|
Pflegeraumkombination (mit Reinigung und Desinfektion) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1000 hPa |
|
Pflegeraumkombination Wandarmatur (m. Reinigung und Desinfektion) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1000 hPa |
|
Sitzbadewanne |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Armbadeplatz (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Dusche gefliest (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Gipsbeckenanlage (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Hubbadewanne (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Instrumentenspültisch (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Medizinische Badewanne (Anschlüsse) |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1000 hPa VR(warm) = 1,00 l/s pminFL(warm) = 1000 hPa |
|
Pflegearbeitsraumkombination (mit Waschmaschine / Anschlüsse) |
|
|
|
|
VR(kalt) = 1,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 1,15 l/s pminFL(warm) = 1000 hPa |
|
Pflegeraumkombination (mit Reinigung und Desinf. - Anschlüsse) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1000 hPa |
|
Sitzbadewanne (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Ausgussbecken (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Badewanne (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Bidet (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Dusche (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Fußwaschbecken (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Küchenspüle (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Küchenspüle mit Wandarmatur (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Küchenspüle- Spülmasch. mit Wandarmatur (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,14 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,14 l/s pminFL(warm) = 1000 hPa |
|
Küchenspüle/Spülmaschine (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,14 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,14 l/s pminFL(warm) = 1000 hPa |
|
Reihendusche (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Reihenwaschanlage (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,05 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,05 l/s pminFL(warm) = 1000 hPa |
|
UP-Bad bzw. Brause (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
UP-Dusche (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
UP-Reihendusche (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,15 l/s pminFL(warm) = 1000 hPa |
|
Waschtisch (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Waschtisch mit Wandarmatur (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Auslaufventil Gartenschlauch (als Dauerverbraucher) |
|
|
|
|
VR(kalt) = 0,67 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,67 l/s pminFL(warm) = 1000 hPa |
|
Auslaufventil Gartenschlauch (als Dauerverbraucher) |
|
|
|
|
VR(kalt) = 0,67 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,67 l/s pminFL(warm) = 1000 hPa |
|
Auslaufventil ohne Luftsprudler |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 500 hPa VR(warm) = 0,30 l/s pminFL(warm) = 500 hPa |
|
Dauerverbraucher |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 500 hPa VR(warm) = 0,30 l/s pminFL(warm) = 500 hPa |
|
FK 4 (Auslaufventil mit Rohrtrenner) |
|
|
|
|
VR(kalt) = 0,78 l/s pminFL(kalt) = 1900 hPa VR(warm) = 0,78 l/s pminFL(warm) = 1900 hPa |
|
Frosti Plus (kein Dauerverbr.) |
|
|
|
|
VR(kalt) = 0,67 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,67 l/s pminFL(warm) = 1000 hPa |
|
Füllkombination |
|
|
|
|
VR(kalt) = 0,20 l/s pminFL(kalt) = 1500 hPa |
|
Sicherheitstrennstation FK 5 |
|
|
|
|
VR(kalt) = 0,83 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,83 l/s pminFL(warm) = 1000 hPa |
|
Wandhydrant Typ S |
|
|
|
|
|
|
Wandhydrant Typ S, hydraulisch relevant |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Autom. Stockwerksregulierventil |
|
|
|
|
|
|
Autom. Strangregulierventil |
|
|
|
|
|
|
Fußstück Inlinerzirkulation |
|
|
|
|
|
|
Kopfstück Inlinerzirkulation |
|
|
|
|
|
|
Layer Verbindung |
|
|
|
|
|
|
Strangregulierventil |
|
|
|
|
|
|
Übergang Zirkulation |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Bogen |
|
|
|
|
|
|
Brandschutzmanschette |
|
|
|
|
|
|
Fixpunkt |
|
|
|
|
|
|
Stütz- und Dehnmuffe |
|
|
|
|
|
|
TS-Teiler |
|
|
|
|
|
|
Übersprung (groß) |
|
|
|
|
|
|
Übersprung (klein) |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Control-Durchflussmessarmatur |
|
|
|
|
|
|
dynamischer Strömungsteiler |
|
|
|
|
|
|
Hygienespülung (PWC) |
|
|
|
|
VR(kalt) = 0,17 l/s pminFL(kalt) = 1000 hPa |
|
Hygienespülung, Doppelanschluss |
|
|
|
|
VR(kalt) = 0,17 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,17 l/s pminFL(warm) = 1000 hPa |
|
Hygiene-Spülventil Typ C (endständig mit Durchflussbegrenzer) |
|
|
|
|
|
|
Layer Verbindung |
|
|
|
|
|
|
Ringleitungs T-Stück |
|
|
|
|
|
|
Temperaturmessarmatur PT 1000 |
|
|
|
|
|
|
VAV mit Motorantrieb |
|
|
|
|
|
|
Vollstromabsperrung AP |
|
|
|
|
|
|
Vollstromabsperrung UP |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Doppelwandwinkel |
|
|
|
|
|
|
Doppelwandwinkel (klein) |
|
|
|
|
|
|
Doppelwandwinkel (links) |
|
|
|
|
|
|
Doppelwandwinkel (rechts) |
|
|
|
|
|
|
HyTwin (klein) |
|
|
|
|
|
|
HyTwin (links) |
|
|
|
|
|
|
HyTwin (rechts) |
|
|
|
|
|
|
Thermotrenner PWC |
|
|
|
|
|
|
Thermotrenner PWH |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Druckerhöhungsanlage |
|
|
|
|
|
|
Druckreduzierventil |
|
|
|
|
|
|
Pumpe |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Druckerhöhungsanlage (klassisch) |
|
|
|
|
|
|
Einzeltrinkwassererwärmer |
|
|
|
|
|
|
Fußstück Inlinerzirkulation |
|
|
|
|
|
|
Gruppentrinkwassererwärmer (elektrisch) |
|
|
|
|
|
|
Instrumentenspültisch |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Kopfstück Inlinerzirkulation |
|
|
|
|
|
|
Küchenspüle |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,07 l/s pminFL(warm) = 1000 hPa |
|
Küchenspüle/Spülmaschine |
|
|
|
|
VR(kalt) = 0,14 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,14 l/s pminFL(warm) = 1000 hPa |
|
Pflegearbeitsraumkombination (mit Waschmaschine) |
|
|
|
|
VR(kalt) = 1,15 l/s pminFL(kalt) = 1000 hPa VR(warm) = 1,15 l/s pminFL(warm) = 1000 hPa |
|
Pflegeraumkombination (mit Reinigung und Desinfektion) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa VR(warm) = 0,30 l/s pminFL(warm) = 1000 hPa |
|
zentraler Trinkwassererwärmer (klassisch) |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Elektro-Durchfluss-Wassererwärmer |
|
|
|
|
|
|
Elektro-Durchfluss-Wassererwärmer UT |
|
|
|
|
|
|
Elektro-Speicher-Wassererwärmer |
|
|
|
|
|
|
Gas-Durchlauf-Wasserheizer |
|
|
|
|
|
|
KTS ThermoBox |
|
|
|
|
|
|
KTS ThermoStation |
|
|
|
|
|
|
KTS ThermoStation (mit PWH-C) |
|
|
|
|
|
|
Wohnungswasserstation |
|
|
|
|
|
|
zentraler Trinkwassererwärmer (TWE) |
|
|
|
|
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Notdusche (Anschlsse) |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1500 hPa |
|
Spülmaschine (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,07 l/s pminFL(kalt) = 500 hPa VR(warm) = 0,07 l/s pminFL(warm) = 500 hPa |
|
Stand-WC mit Druckspüler (Anschlüsse) |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1200 hPa |
|
Stand-WC mit Spülkasten (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Urinal elektronisch (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa |
|
Urinal pneumatisch gesteuert (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,30 l/s pminFL(kalt) = 1000 hPa |
|
Waschmaschine (Anschlüsse) |
|
|
|
|
VR(kalt) = 0,15 l/s pminFL(kalt) = 500 hPa VR(warm) = 0,15 l/s pminFL(warm) = 500 hPa |
|
WC Spülkasten UP,Bet. von vorne, Umluft/Abluft |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
WC-Druckspüler (Anschlüsse) |
|
|
|
|
VR(kalt) = 1,00 l/s pminFL(kalt) = 1200 hPa |
|
WC-Spülkasten (Aufputz-Anschlüsse) |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
WC-Spülkasten (Unterputz-Anschlüsse) |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
WC-Spülkasten (von vorn-Anschlüsse) |
|
|
|
|
VR(kalt) = 0,13 l/s pminFL(kalt) = 500 hPa |
|
Bezeichnung |
Symbol |
Schema DIN |
Schema Komfort |
Grundriss |
Technische Daten |
|---|---|---|---|---|---|
|
Strang (Durchgang nach Oben) |
|
|
|
|
|
|
Strang (Durchgang nach unten) |
|
|
|
|
|
|
Strang (nach Oben) |
|
|
|
|
|
|
Strang (nach Unten) |
|
|
|
|
|
|
Strang (von Oben) |
|
|
|
|
|
|
Strang (von Unten) |
|
|
|
|
